CNC Shield V4.0 3-Axis Stepper Motor Drive Board

Name: CNC Shield V4.0 3-Axis Stepper Motor Drive Board - MechBlock
Brand: MECHBLOCK
SKU: MB-3ASMDB
Price: 190.00 INR
Availability: InStock
Rating: 4.94 (48 reviews)

MECHBLOCK

Rated 4.94 out of 5 based on 48 customer ratings

(48 customer reviews)

Original price was: ₹240.00.Current price is: ₹190.00. Incl GST (₹161.02 +18%GST)

Compatible with a micro-drive laser engraving machine, three-axis CNC engraving machine.
2A can be controlled within the two-phase four-wire stepper motor.
Power DC5V interface, 7.5-12V voltage input.
GRBL compatible.
Worked with Arduino nano.

EAN: 8903470451223 SKU: MB-3ASMDB Category: Clearance Tag: Clearance

In stock

Purchase & earn 2 MechBlock points!

Check Estimated Delivery at

Shipping to IN

Add ₹499.00 to cart and get free shipping! Free shipping over 499/-

16 People watching this product now!

Mechblock Shopping Event

Hurry and get discounts on all Mechblock Products up to Rs.1000

Coupon code: MECHBLOCK

Description:

CNC shield V4 needs to work with the Nano board.
It can be used as a driver’s expansion board for engraving machines and 3D printers.
It has in total 3 channel slots for stepper motor driver modules (not included) for driving 3 channels of stepper motors.
Each channel of stepper motor only needs 2 IO ports, which means 6 IO ports are sufficient to manage 3 stepper motors.
This shield can make quick work for managing stepper motors in your project.

Features :

3 Axis stepper motor driver.
Compatible with a micro-drive laser engraving machine, a three-axis CNC engraving machine.
2A can be controlled within the two-phase four-wire stepper motor.
Power DC5V interface, 7.5-12V voltage input.
GRBL compatible.
Worked with Arduino Nano.

Package Include:

CNC Shield V4.0 3-Axis Stepper Motor Drive Board -1Pc

Weight	0.05 kg
Brand	MECHBLOCK
Condition	New
HSN Code	84678990

15 Days Warranty

This item is covered with a standard warranty of 15 days from the time of delivery against manufacturing defects only. This warranty is given for the benefit of Mechblock customers from any kind of manufacturing defects. Reimbursement or replacement will be done against manufacturing defects.

What voids warranty:

If the product is subject to misuse, tampering, static discharge,mishandelling of the product, accident, water or fire damage, use of chemicals & soldered or altered in any way.
