XTool P3 80W co2 Laser Cutter & Engraver
₹774,999.00 (Inc. GST) ₹118,220.19 GST Input (18%) Claimable with B2B Billing. Enter GST number at checkout.
- 80W CO2 laser with optional 5W IR module
- 915 × 458 mm working area with conveyor support
- Max processing speed of 1200 mm/s
- Dual-camera positioning with 0.2 mm precision
- AI-powered features like Smart Nesting and Batch Fill
- Class 1 laser safety with fire detection and suppression
Ship Location – Delhi Warehouse
Description
The xTool P3 80W CO2 Laser Cutter is a flagship production-grade machine designed for manufacturers, prototyping labs, makerspaces, and creative studios. With its 80W CO2 laser power, large 36 × 18 inch bed, and intelligent automation system, it enables faster throughput, consistent precision and a smooth workflow.
Flagship 80W CO2 Laser Power for Industrial-Grade Cutting: Unleash powerful performance. This professional-grade xTool P3 CO2 laser engraver effortlessly cuts 20mm wood and 25mm acrylic. At 1200mm/s max speed, this laser cutter machine masters materials diode laser engraver can’t touch (like clear acrylic) with cleaner, faster results, making it the ideal laser cutting machine.
Revolutionary Automated Creation System: Experience a true “Place & Go” workflow. ACS integrates LiDAR ranging for perfect autofocus, dual HD cameras for precise positioning, & an AutoLift Base (up to 8.7″ height) to automate setup, significantly simplifying the operation of this advanced CO2 laser cutter.
Largest Desktop Area & Dual-Cam Precision: Command a massive 36″ × 18″ workspace. The Evolved Dual HD Camera system (16MP SkyView + close-range detail cam) provides a distortion-free preview & microscopic 0.0079″ alignment accuracy, ensuring professional results from your laser engraver machine.
Streamlined Pro Workflow: Maximize efficiency & minimize waste. AI-powered Smart Nesting achieves 98.7% material utilization. Use Variable Batch Fill with spreadsheet import for mass customization, streamlining your CO2 laser operations.
XTOOL P3 Supported Materials List
Why Choose xTool P3 80W CO2 Laser Cutter?
High Power & Cutting Capacity
80W CO2 laser module with optional 5W IR support for coated metals
Cuts up to 25 mm acrylic and 20 mm basswood in a single pass
1200 mm/s maximum speed for industrial-grade productivity
Large Working Area for Bigger Jobs
914 × 457 mm (36 × 18 inch) work bed
Process large parts or multiple smaller parts in one run
Increases throughput and reduces handling time
Intelligent Workflow Automation
ACS smart workflow with autofocus, auto-positioning, LiDAR ranging, auto-lifting base
4-camera vision system with live preview for exact placement
0.02 mm positioning accuracy and 0.01 mm motion precision
Advanced Safety Features
Certified Class 1 laser safety with enclosures
Includes SafetyPro™ IF 2.0 safety module
Integrated flame suppression options
Versatility & Expandability
Works on 300+ materials: wood, acrylic, glass, ceramics, leather, fabric, coated metals (IR module)
Supports rotary engraving for cylindrical products (bottles, tumblers)
Compatible with RA3 rotary tool and conveyor system for continuous production
Applications of xTool P3 80W CO2 Laser Cutter
Prototyping & manufacturing – furniture parts, signage, packaging inserts
Retail customization – engraved glassware, stone décor, awards
Industrial design & fashion – acrylic, leather, fabric cutting
Rotary engraving – bottles, tumblers, wooden cylinders
Metal marking (with IR module) – aluminum, coated metals
User Experience & Workflow
ACS automation reduces manual setup & calibration
Live multi-camera preview ensures accuracy before each job
xTool Studio software (Windows/macOS) supports SVG, DXF, JPG, PNG formats
USB and Wi-Fi connectivity for flexible workflow integration
Expandable with conveyor feeding system for batch production
Comparison & Value
Vs. desktop cutters → much larger bed, stronger cutting power, automated workflow
Vs. entry-level industrial machines → modern vision-based operation and faster setup
Safety module → ready to use immediately
Delivers a strong ROI for businesses scaling production
Installation, Safety, and Support
Distributed officially in India by Mechblock
Includes Safety Instructions, Quick Start Guide, and SafetyPro™ IF 2.0 module
Installation and operator training services available
Backed by official warranty and nationwide support
Extended warranty & service agreements available for enterprises
Who Should Buy This Machine?
Commercial workshops & prototyping labs needing industrial power in a compact form
Design studios & manufacturers requiring repeatability and high throughput
Retail gift & customization shops seeking precision and fast turnaround
Educational institutions & makerspaces demanding a safe, easy-to-use laser cutter
xTool P3 vs xTool P2S
| Feature | xTool P3 | xTool P2S |
|---|---|---|
| Laser Type | 80W CO₂ Laser + Optional 5W IR Laser | 55W CO₂ Laser |
| Working Area | 915 × 458 mm (36″ × 18″) | 600 × 305 mm (23.6″ × 12″) |
| Maximum Engraving Speed | 1,200 mm/s (X-axis Acceleration: 19,600 mm/s²) | 600 mm/s (X-axis Acceleration: 6,400 mm/s²) |
| Basswood Cutting | Up to 20 mm (One Pass) | Up to 18 mm (One Pass) |
| Acrylic Cutting | Up to 25 mm (One Pass) | Up to 20 mm (One Pass) |
| Maximum Processing Height | 220 mm | Up to 215 mm (with Riser Base) |
| Maximum Rotary Diameter | 200 mm | 180 mm (with Riser Base) |
| Built-in Cameras | 16 MP Panoramic + Close-range + Dual Side Cameras | 16 MP Panoramic + Close-range Cameras |
| ACS™ (Automated Creation System) | Yes | No |
| Positioning Precision | 0.2 mm | 0.3 mm |
| Motion Accuracy | 0.01 mm | 0.015 mm |
| Laser Safety | Class 1 | Class 4 |
| Machine Weight | 105 kg | 45 kg |
| Maximum Power Consumption | 1,400 W | 700 W |
| Best For | Industrial production, large-format cutting, high-speed engraving, and advanced automation | Professional CO₂ laser cutting and engraving for small to medium businesses |
Warranty & Delivery Information
- This xTool product comes with a 1-Year Standard Manufacturer Warranty.
- Warranty covers manufacturing defects only.
- Warranty support is provided in India by Mechblock– Authorized xTool Distributor.
- Warranty is valid only with original invoice and serial number.
- Accessories, consumables, and wear-and-tear parts are not covered under warranty.
Warranty does not cover:
- Physical or accidental damage
- Damage due to misuse or improper installation
- Unauthorized repairs or third-party modifications
- Warranty process timeline depends on part availability.
For warranty support:
Email: support@mechblock.in
Phone: +91 7840810400
Delivery & Shipping Information
- PAN-India delivery available
- Estimated delivery time: 5–10 business days (location dependent) and availability of goods
- Pre-order products may take between 35-45 working days
- Secure packaging and insured shipping
- Tracking details shared via WhatsApp / Email after dispatch
- Installation Not Included Professional installation is available at additional charges. Contact support for details.
For urgent delivery or installation requests, please contact our sales team.
Specification
Overview
| Weight | 130 kg |
|---|---|
| Dimensions | 25 × 25 × 25 cm |
| Package | Standalone, Versatile Bundle, All-in-one-Bundle |
| HSN Code | 84561100 |
| Laser Type | CO2 |
| Processing Mode | Laser Cutting Laser Engraving |
| Supported Materials | Laser Cuttable: Wood, Acrylic, Fabric, Leather and more Laser Engravable: Metal, Glass, Bamboo,Ceramic and more |
| Working Area(mm) | 915×458 |
| Max. Working Speed | 1200 mm/s |
| Supported Software | xTool Studio |
| Operating System | Windows/macOS |
| Connection Method | USB/Wi-Fi |
| Supported Files | SVG/DXF/JPG/JPEG/PNG/BMP/TIF |
| Almake Compatibility | Yes |
| Easy Operation | Yes |
| Built-in Camera | 16 MP SkyView Panoramic Camera + Close-range Camera + Side Camera × 2 |
| Positioning Method | Dual-Camera Positioning |
| Focus Mode | Autofocus |
| Preview Method | Smart Camera Preview |
| Laser Spot Size | S Focal Lens: 0.0055″ × 0.0063″ (0.14 mm × 0.16 mm) (optional) M Focal Lens: 0.0059″ × 0.0071″ (0.15 mm × 0.18 mm) (standard) L Focal Lens: 0.0071″ × 0.0079″ (0.18 mm × 0.20 mm) (optional) |
| Positioning Precision | 0.0079″ (0.2 mm), Camera |
| Motion Accuracy | 0.00039″ (0.01 mm) |
| Safety Certification | Class 1 Laser Safety |
| Product Dimensions | 49.2″ × 30.7″ × 19.5 |
| Product Weight | 105 KG |
| Power Adapter Input Voltage | 100 V – 240 V, AC 50/60 Hz |
| Brand | XTOOL |
| Machine Electric Power | 1400W |
| Laser Spot Size(mm) | S Lens: 0.14 mm × 0.16 mm, M Lens (Standard): 0.15 mm × 0.18 mm, L Lens: 0.18 mm × 0.20 mm |
| Laser Wavelenght | 10,600nm |
| Model | xTool P3 80W |
| Cutting Material | acrylic, cardboard, fabric, leather, rubber, wood |
| Engraving Compatibility | acrylic, ceramic, glass, leather, Slate, Stone, wood |
