The Mightiest Cutting Ability

18mm hardwood cutting in one-pass
15mm black acrylic cutting in one-pass
0.1mm stainless metal cutting in one-pass
Maximum thickness of one-pass cutting
Laser Module | 40W | 20W |
---|---|---|
Pine Wood | 20mm | 15mm |
Cherry Wood | 18mm | 10mm |
Basswood Plywood | 15mm | 10mm |
Walnut Wood | 15mm | 10mm |
Black Acrylic | 15mm | 8mm |
Stainless Metal | 0.1mm | 0.04mm |
The 10W Diode Laser Module
The Ultrafine Engraving

Ultrafine Engraving Line Thickness
Smaller laser focus (from 0.15*0.15mm to 0.08*0.06mm) and tiny engraving line width makes for impeccable details, thanks to the compressed-spot technology.

100% Reprint Your Laser Engraving Ideas

Higher Productivity at A Higher Speed




* To engrave at the highest speed, please use a higher performance computer or process offline.
Improve The Accuracy to The Extreme

Why D1 Pro Provide the Highest Accuracy
engraving/cutting accuracy to reach 0.0004 inches repositioning accuracy down to less than 0.0007 inches.
Easy Focus Adjustment
Only take 3 steps to adjust the focus in 5 seconds. Pull down the original focus lever, slide the laser slider to make the focus lever close to the material’s surface, recover the focus lever.
Precise Focus Adjustment for Thicker Cutting
To ensure the cutting capacity of the laser,
the focal length can be adjusted by lifting or
lowering the laser module according to the
thickness of the materials.
Invigorate Your Creations with 340+ Colors
Super powerful 20W laser beam oxidizes the metallic surface in an instant, bringing vivid colors to the engraved metal.

Limit Switches in All Directions

Limit switches will trigger the alarm if the laser head is about to hit the boundary of the machine in All Directions.
Safe to Use
The emergency stop will be triggered by the detection of flames, smoke and tipping.


Better Software at Your Service
Get started quickly with our user-friendly software: XCS
Updating Project Files Batch Processing with Circular Array Default Working Parameters for Materials


Details Matters

The Risers
Use additional risers (sold separately) to increase the height of xTool D1 Pro to facilitate the engraving of higher objects(use 2 sets to increase height to 140mm). Customize your skateboard or basketball to make them cooler.
Just Connect
You can transfer data via Wi-Fi, USB cable, a large capacity TF card (Offline Use) and use D1 Pro anytime and anywhere.
Specs:
Type | xTool D1 Pro-40W Laser Module | xTool D1 Pro-10W |
---|---|---|
Machine Power | 200 W | 60W |
Laser Electric Power | 144 W | 40W |
Laser Module Output Power | 40W | 10W |
Laser Spot | 0.1*0.15mm | 0.08*0.06 mm |
Routing Speed | 400 mm/s | 400 mm/s |
Working Area | 430 * 390 mm (16.93 * 15.35 inch) | 430*400 mm(16.93*15.75 inch) |
Max. Workpiece Height | 50 mm (2 inch) | 50 mm (2 inch) |
Max. Workpiece Height with X risers | 50mm+X*45mm(each set riser height column) | 50mm+X*45mm(each set riser height column) |
Connecting Interfaces | USB/Wi-Fi/TF Card | USB/Wi-Fi/TF Card |
Certification | FCC / FDA / CE | FCC / FDA / CE |
Operating Systems | Windows/macOS | Windows/macOS |
Control Software | xTool Creative Space / LightBurn | xTool Creative Space / LightBurn |
File Type(s) | SVG/DXF/JPG/JPEG/PNG/BMP/TIF/CR2, etc. | SVG/DXF/JPG/JPEG/PNG/BMP/TIF/CR2, etc. |
